• Model : WKM2NGFF
• Capacity: 128GB,256GB,512GB,1TB,2TB
• 1G~8Gbits Internal Cache
• Form Factor: M.2/NGFF
• Supports 1-port1.5/3.0/6.0Gbps SATA I/II/III interface.
• SMART feature set and 48-bit Address feature set
• Compatibility: Full SATA hard disk compatible
• Ultra rugged and reliable
• High-speed performance
• Silent, no moving parts
• Data retention: JESD47 compliant
• Proprietary wear leveling algorithms
• 100% tested hardware and software
• Data Retention: JESD47 compliant
• Wear Leveling: Static and dynamic wear-leveling algorithm.
• Bad Block Management: Failed Blocks of Flash will be replaced with new ones by the SSD.
• ECC/EDC (Error Correction Code/Error Detection Code):
-Hard ware ECC engine: LDCP ECC engine On-the-fly operation 16bit CRC to ensure storage-data integrity between controller and NAND Flash device
• MTBF: >1,000,000hours
• Power Cycle:1000 times
• Operating Voltage Requirement: Vcc=3.3V +/-10%
